| M | L | |
| ① Seat Tube | 440mm | 470mm |
| ② Seat Tube Angle | 71.5° | 71.5° |
| ③ Head Tube | 130mm | 130mm |
| ④ Head Tube Angl | 64° | 64° |
| ⑤ Bottom Bracket Offset | -8 | -8 |
| ⑥ Chain Stay | 470mm | 470mm |
| ⑦ Top Tube (horizontal） | 610mm | 638mm |
| ⑧ Length Specified Fork +Headset | 585mm | 585mm |
| ⑨ Offset Specified Fork | 44mm | 44mm |
| ⑩ Length Specified Shock | 250/230mm | 250/230mm |
| ★ Travel Specified Shock | 75/65mm | 75/65mm |
| ⑪ Rear Wheel Travel | 187.4/167.3mm | 187.4/167.3mm |
| ★ Maximum Allowed Front Fork Travel | 180mm | 180mm |
| ⑫ Wheelbase | 1263mm | 1291mm |
| ⑬ Reach | 440.8mm | 468mm |
| ⑭ Stack | 631mm | 631mm |
 LINKAGEAs the most important part connecting shock to the frame, the replaceable conversion link makes it possible to switch easily between 230 and 250 shocks. Usually longer shocks provide a greater rear wheel travel, thus more aggressive riding may be allowed to deal with more complex road conditions. |  turning point SCREWSStainless steel forged screws instead of the aluminum alloy ones that most brands use are adopted at turning point. Although losing the advantage in weight, they are increased in strength to cope with the strong torque of the motor. |
 internal cable routineFor optimal protection, all cables (wires, shift cables and brake cables) are routed almost completely through the frame. Through the cable hole at the head tube, they enter the internal tubes to achieve the most effective protection. The motor seat, through further improvement, may prevent the squeezing or pulling of the cables during compression. |  four linkOur outstanding suspension technology provides sensitivity off the top, with good mid-stroke support and plenty of end-stroke progressivity. The nice pop helps get the bike airborne whenever wanted, while the end-stroke progressivity makes sure the rear shock doesn't bottom out even on monster jumps. The high amount of anti-squat keeps the rear suspension neutral and improves pedal efficiency. |
 Choose internationally renowned brand accessories, and pass a number of professional tests such as battery explosion-proof test, uphill test, and electronic control system test. The 7-layer corrugated paper is used for packaging, which is strong and compressive to ensure that the electric vehicle is not damaged during transportation. As an experienced electric bicycle manufacturer and supplier from China, PLUS EBIKE always produces high-quality OEM/ODM electric bicycles including mountain e-bike, city e-bike and folding e-bike. Service centers are set up in the UK and Switzerland, and the professional team of PLUS EBIKE provides high-quality and convenient after-sales service at any time. |
 |  |  |
